A NEW INDUSTRY STANDARD

The A7V is a contemporary 2-way monitor that represents the evolution of ADAM Audio’s award winning A7X. It features a 7” Multi-Layer Mineral woofer and rotatable X-ART tweeter, which is made by hand in Berlin.

DSP-based voicing, equalization and room correction options can be controlled remotely and in real time via the free-to-download A Control software, and updatable firmware allows for new filters and tunings to be implemented over the lifetime of the monitor.

• German Handmade Precision X-ART Tweeter with rotatable HPS waveguide
• 7'' Woofer (Multi-Layer Mineral)
• Total Peak Amp. Power: 130 W
• Frequency Response @ -6 dB: 40 Hz - 45 kHz
• Max. peak SPL per speaker at 1 m: 105 dB SPL

Display: Front panel multi-colour LED

Cabinet Design: Dual front ported

Cabinet Material: Vinyl wrapped MDF and painted MDF front panel

Mounting options: Threaded inserts on the bottom of the cabinet (4 x M8)

Power consumption (max, idle, sleep): 220 W, 10 W, 3.5 W

AC Input Voltage: 100 – 240 V, 50/60 Hz

Power Rating: 300 W max.

Operating Conditions:-10° C to +40° C (+14° F to +104° F); <75 % RH, non-condensing

Weight: 8.7 kg (19 lb 3 oz)

Dimensions (Height x Width x Depth): 337 mm x 200 mm x 280 mm (13 1/4″ x 7 7/8″ x 11″)

Warranty: 5 years (2 years warranty plus 3 years optional with product registration)

Delivery Contents: A7V loudspeaker, power cable, Quick Start Guide
