YAMAHA-DBR10

Ref: YA DBR10

YAMAHA-DBR10

The DBR10 is the most compact model in its series and in its class. Capable of delivering a maximum SPL of 129dB from its compact enclosure, the DBR10 can be used as a utility..." Leia mais

SOB CONSULTA

€ 438,00

ADICIONAR

The DBR10 is the most compact model in its series and in its class. Capable of delivering a maximum SPL of 129dB from its compact enclosure, the DBR10 can be used as a utility speaker in a variety of environments.

Speaker type		2-way, Bi-amp powered speaker, Bass-reflex type
Frequency range (-10dB)		55Hz – 20kHz
Nominal coverage	H	90°
Nominal coverage	V	60°
Components	LF	Diameter:10" cone, Voice Coil:2", Magnet:Ferrite
Components	HF	Diaphragm:1", Type: 1" throat compression driver, Magnet:Ferrite
Crossover		2.1kHz: FIR-X tuning™ (linear phase FIR filter)
Output power		Dynamic:700 W (LF: 500 W, HF: 200 W) / Continuous: 325 W (LF: 260 W, HF: 65 W)
Maximum output level (1m; on axis)		129dB SPL
I/O connectors		INPUT1: Combo x1, INPUT2: Combo x 1 + RCA pin x 2 (Unbalanced), OUTPUT: XLR3-32 x 1 (CH1 Parallel Through or CH1+CH2 Mix)
Processors		D-CONTOUR: FOH/MAIN, MONITOR, OFF
Heat dissipation		Fan cooling, 4 speeds
Power requirements		100 V, 100-120V, 220-240 V, 110/127/220V (Brazil), 50/60Hz
Power consumption		60W(1/8 Power Consumption), 18W(Idle)
Cabinet material		Plastic
Finish		Black
Handle		Top x 1
Flying and mounting hardware		Bottom x 2 (Fit for M8 x 15 mm eyebolts)
Pole socket		35mm (Bottom x 1)
Dimensions	W	308mm (12.1")
	H	493mm (19.4")
	D	289mm (11.4")
Net weight		10.5 kg (23.2 lbs)
Accessories		BBS251, BCS251, BWS251-300, BWS251-400 (Optional Speaker bracket)
