GRAND SOUND FOR THE LIVING ROOM

This instrument brings life to the finest nuances of globally renowned grand pianos. The high-quality amplifier system with newly developed speakers creates a sound as complex as that produced by acoustic grand pianos.

26 different tones are available, including three famous grand piano sounds. Other special features, such as the Concert Play and Hall Simulator functions leave very little to be desired for ambitious piano playing.

Specification

Keyboard	88-key piano keyboard Layer, Split Duet: Adjustable tone range (-2 to +2 octaves) Transpose: -12 semitones to 0 to +12 semitones Octave shift: 4 octaves (-2 to 0 to +2)
Sound Source	Number of Tones: 26 Maximum polyphony: 256 notes Touch Response: 5 sensitivity levels, Off Tuning: 415.5Hz to 440.0Hz to 465.9Hz (0.1Hz units) Temperament: Equal temperament plus 16 other types Stretch Tuning: 5 types, Off, Auto Setting
Acoustic Simulator	String resonance, Damper resonance, Damper noise, Key on action noise, Key off action noise, Hammer response, Lid simulator
Effects	Hall simulator (12 types), Chorus (4 types), Brilliance (-3 to 0 to 3), DSP, Headphone mode
Concert Play	Number of Songs: 15 Playback of Concert Play songs obtained with a computer, etc. Song volume: Adjustable Playback at 80% of normal tempo 2 Modes: LISTEN, PLAY
Music Library	Number of Songs: 60, User Songs: 10 (Up to approximately 90KB per song, approximately 900KB for 10 songs)* Based on 1KB = 1024 bytes, 1MB = 1024² bytes Song volume: Adjustable Part On/Off: L, R
Grand Piano demo song	6
MIDI Recorder	Functions: Real-time recording, playback Number of Songs: 1 Number of Tracks: 2 Capacity: Approximately 5,000 notes total Recorded Data Protection: Built-in flash memory MIDI Recorder Volume Level: Adjustable
Audio Recorder	Real-time recording and playback to USB flash drive* Linear PCM, 16bit, 44.1kHz, stereo .WAV format Songs: 99 files Approximately 25 minutes maximum recording per file. Audio Recorder Volume Level: Adjustable
Metronome	Beats: 0 to 9 Tempo Range: 20 to 255 Metronome Volume Level: Adjustable
Pedals	Damper (with half-pedal operation), Soft, Sostenuto
Other Functions	Setting backup Operation Lock
MIDI	16-chanel multi-timbre receive
USB Flash Drive	Capacity: 32GB or less recommended SMF direct playback, data storage, data loading, USB flash drive format, audio data playback and storage, scene storage
Inputs/Outputs	PHONES jacks: Stereo standard jacks x 2 Power: 24V DC MIDI OUT/IN terminals LINE IN R, L/MONO jacks: Standard jacks x 2/ Input impedance: 9.0kΩ, Input voltage: 200mV LINE OUT R, L/MONO jacks: Standard jacks x 2/ Output impedance: 2.3kΩ, Output voltage: 1.8V (RMS) MAX USB port: Type B USB flash drive port: Type A Pedal connector
Acoustics	Amp output: 30W x 2 + 20W x 2 Speakers: 16cm x 2 + (10cm + 5cm) x 2 Volume sync equalizer (3 types, Off)
Power Requirements	AC Adaptor: AD-E24500LW Auto Power Off: Approximately 4 hours after last operation. Auto Power Off can be disabled.
Power Consumption	38W
Dimensions	143.4 (W) x 48.9 (D) x 96.3 (H) cm
Weight	78.5 kg
