SPEC

• body shape: Cutaway Dreadnought body
• top: Spruce top
• back & sides: Okoume back & Okoume sides
• neck: PF Nyatoh neck
• fretboard: Merbau fretboard
• bridge: Merbau bridge
• inlay: White dot
• soundhole rosette: Laser engraved rosette
• tuning machine: Chrome Die-cast Tuner
• nut material: Plastic
• number of frets: 20
• saddle material: Plastic
• bridge pins: Ibanez Advantage™
• strings: Ibanez IACS6C
• string space: 11mm
• pickup: Ibanez Under Saddle
• preamp: Ibanez AEQ-2T preamp w/Onboard tuner
• output jack: 1/4" output

NECK DIMENSIONS

• Scale : 648mm
• a : Width: 42mm at NUT
• b : Width: 54mm at 14F
• c : Thickness: 21mm at 1F
• d : Thickness: 22.5mm at 7F
• Radius : 240mmR

BODY DIMENSIONS

• a : Length: 20 "
• b : Width: 15 3/4"
• c : Max Depth: 5"

PREAMP

De momento não existe informação disponível
