SPECS

• body shape: Grand Concert body
• top: Okoume top
• back & sides: Okoume back & Okoume sides
• neck: PCBEMaple neck
• fretboard: Laurel fretboard
• bridge: Laurel
• inlay: Black with white dot
• soundhole rosette: Tortoiseshell
• tuning machine: Chrome Die-cast tuners
• nut material: Plastic
• number of frets: 20
• saddle material: Plastic
• bridge pins: Black with white dot
• strings: Ibanez IABS4XC32 Carbon coated
• string gauge: .040/.060/.075/.095
• string space: 19mm
• factory tuning: 1G,2D,3A,4E
• pickup: Ibanez Undersaddle
• preamp: Ibanez AEQ-2T preamp w/Onboard tuner
• output jack: 1/4" output

NECK DIMENSIONS

• Scale : 810mm
• a : Width: 43mm at NUT
• b : Width: 58mm at 14F
• c : Thickness: 21mm at 1F
• d : Thickness: 23.5mm at 7F
• Radius : 400mmR

BODY DIMENSIONS

• a : Length: 19 1/4"
• b : Width: 15 1/4"
• c : Max Depth: 4 1/4"

PREAMP

De momento não existe informação disponível
