The DSL40 Combo has been designed with a 12” G-12 V-Type speaker for those who need exceptional tone and flexibility.

With rich functionality including the ability to move between two sounds within each gain channel, players can experiment and release their personality through sound.

Designed and engineered in UK. Made in Vietnam.

Features

• All-valve
• 40W to 20W at the flick of a switch
• 12-inch Celestion V-Type speaker
• Five speaker outputs
• Compact and portable
• Suitable for a variety of genres

GENERAL

Model: DSL40 Combo

Range: DSL

CHANNELS: 2, EACH WITH 2 MODES

TECHNOLOGY: Valve

ELECTRONICS

Output wattage: 40W (with power reduction option to 20W)

OUTPUTS: Speaker outputs: 5 x 1/4" jack sockets (16Ω load / 8Ω load / 4Ω load), 1 x 1/4" jack emulated line out

INPUTS: 1 x 1/4" instrument jack, 1 x 3.5mm jack Auxiliary MIDI input, footswitch

controls: Classic gain channel (gain, volume, clean crunch switch), ultra gain channel (gain, volume, OD1/OD2 switch), treble, middle, bass, tone shift switch, presence, resonance, reverb (classic gain channel), reverb (ultra gain channel), master select switch, master volume I, master volume II, loop on/off switch, low power option (on rear)

Effects: Digital reverb

Effects loop: Yes, series, send/return

SPEAKERS

Speaker configuration: 1x12"

Speaker model: Celestion V-Type speaker (16Ω, 70w)

Unit impedance: 16Ω

VALVES

Preamp valves: 4 x ECC83

Power amp valves: 2 x EL34

PHYSICAL UNIT

Weight: 22.9 kg / 50 LB

Width: 620 mm / 24.4"

Height: 490 mm / 19.3"

Depth: 252 mm / 9.9"

Country of origin: Designed and engineered in UK. Made in Vietnam.

INCLUDED IN THE BOX

PEDL-90012 included.

Compatible with PEDL-91016 modes include: 1 - Clean (classic green) 2 - Crunch (classic red) 3 - OD1 (ultra green) 4 - OD2 (ultra red) 5 - Master 1/Master 2 (toggle) 6 - FX Loop on/off

Detachable power cable included
